Roscamat is a brand of TECNOSPIRO MACHINE TOOL, established in 1987. Initially created to meet the production needs of Spiroide, a manufacturer of bevel gears within the Spirogear Group Companies, Roscamat has since become a global leader in tapping arm technology.

With over 36 years of experience and a presence in more than 85 countries, Roscamat boasts a successful track record of providing innovative tapping solutions. Their articulated tapping arms, capable of handling threads from M2 to M42, are renowned for their versatility and efficiency. Available in both pneumatic and electric configurations, these arms are also used for various other machining operations, including chamfering, countersinking, drilling, reaming, and inserting.

Roscamat prides itself on being at the forefront of technological advancements. Their electric machines, in particular, offer significant advantages such as lower power consumption and reduced noise levels.

Why Roscamat?

Quality & Dependability

• Heavy duty cast aluminum construction
• More than 32 years experience designing, manufacturing and servicing tapping arms
• Adjustable balance for easy maneuverability
• Premium fit and finish

Light & Versatile

•  Light weight and compact size allow for easy set up and relocation
• Reaming, countersinking, fastening, inserts & small diameter drilling

Practical & Simple

•  Uses standard quick change tap adapters
• Utilize interchangeable speed modules to get the right torque and RPM for the job
• Wide range of models and options allow you to precisely choose the perfect arm for your application

Reliable & Safe

• One year warranty against defects in materials and workmanship
• Robust materials & construction exceed design standards providing a lifetime of use
• Precisely Engineered Motors
• Roscamat® motors are designed, engineered, and built for tapping
• High frequency, low noise electric motor uses 8.5x less energy than pneumatic

Achieve Better Efficiency and Productivity

• Reduce or Eliminate Tap Breakage: Using quick change torque control tap adapters, the clutch in the adapter ratchets when the tap hits the bottom of the hole, encounters an interference in the hole or when the tap dulls. This prevents tap breakage and allows for the tap to be quickly replaced if needed.
• Maximize Manpower: By placing a Roscamat®USA tapping arm next to your machining center, a significant improvement in productivity can be achieved. While the machining center is drilling holes in the next part the operator can be tapping the holes in the previous part. Typically, tapping is the slowest and last operation on a machining center.
• Take the Guess Work Out of the Process: With Roscamat® tapping arms the operator can bring the tap to the work which is 3-4 times more efficient than bringing the work piece to a fixed spindle.
•  More Efficient Tapping: By utilizing quick change modules and tap adapters the proper speed and torque can be achieved for different tap sizes to improve efficiency and productivity.

Reach 765 mm. - 30”

Height 515 mm. -20”

• Single Phase 220/230 V. – Available at 110 V.
• Heavy duty cast aluminium construction
• Base elevator
• High frequency Electric Motor
• Speed control foward & reverse
• Tap adaptors of size 19/1 for quick change

OPTIONS AVAILABLE

• Vertical tapping
• Vertical & Horizontal tapping –VH- (4x90º)
• Tool lubrication with timer

Reach 1020 mm. -40”

Height 535 mm. -21”

TAP UP TO M27 – 1”

• 220/230 V. Single Phase
• High frequency motor
• Speed control foward & reverse
• 1 Motor 7speed capabilities
• 7 interchangeable speed modules
• Heavy duty cast aluminium construction

OPTIONS AVAILABLE

• Vertical tapping
• Vertical & Horizontal tapping -VH- (4x90º)
• Tool lubrication with timer
• Tapping depth control

Modular System - Interchangeable Speed
